Posted on

Automatic Sliding Gate McCauley House – Limavady

Finished in a metallic black, this Inova Basis Automatic Sliding Gate was tailor made to suit our client’s design and needs for there residential property.

Additionally our client requested that their wall railings also incorporate the same design as the Inova automatic gates infill, providing a consistent design throughout the project.

Posted on

Inova Industrial Sliding Gate – Two Trees Recovery Services

This Inova Industrial sliding gate is finished using a solid aluminium sheeting in order to provide a solid privacy screen, complete with a palisade infill fascade to provide a profiled gate design, as required by our client at design stage.

This 7.5m clear opening x 2.4m high Inova sliding gate was designed to provide a large unobstructed passage for the recovery vehicles/ lorries to access with ease whilst providing a high security sliding gate.

Posted on

Industrial Sliding Gate – Junction One Shopping Complex, Antrim

This Inova Industrial sliding gate 280 ESI Model fully automatic, is finished in light grey (RAL 7035) as specified by the client, complete with 25 mm vertical infill bars as standard.

This 6.0m clear opening x 2.0m high Inova sliding gate was designed to provide a large unobstructed access for lorries entering the shopping complex with stock deliveries with ease.

Posted on

High Security Automatic Sliding Gate – Rathgael House, Bangor

This Inova Specialist High Security Automatic Sliding Gate was tailor made to suit our client’s specific design and requirements for their business premises.

The 4.5m high Inova high security  gate was manufactured in two sections. The bottom section of this automatic high security gate being clad in timber infill panels, and the top section of the sliding high security gate clad in mesh panels in order to let natural day-light flood into its premises as well as providing a high secure compound.

Client gave outstanding testimonial on the performance and reliability of this high security gate unit.

Inova high security gates can be designed and manufactured to suit individual client specifications – with numerous sophisticated entry and exit options to compliment the high security gates.

Posted on

National Grid Sub-Station – Offerton

This 6500 mm x 3400 mm Inova Industrial Cantilever sliding gate 280 ESI Model fully automatic, incorporates a palisade infill to match the perimeter fence. Finished in light grey (RAL 7035), this Inova gate also includes 10Kv induced pulse wires complete with electro fence extensions which span from the ground level up to 1.050m above the Inova sliding gate and around the complete sub-station perimeter providing a highly secured area.

This Inova cantilever sliding gate comes complete with all safety edges, key activated switch, remote control, soft start and special inoflex control. Sliding gate has w-section infill pales at 100 mm centres complete with 25 x 25 mm weld-mesh behind pales.

Posted on

National Grid Sub-Station – Isle of Grain

This 6500 mm clear opening x 2400 mm high Inova Industrial sliding automatic gate 280 Model fully automatic, complete with 1200 mm high electro fence extensions for 10Kv induced pulse wires provides a highly secure sub-station compound. It comes complete with all safety edges, key activated switches and remote controls.

Finished in light grey (RAL 7035), this Inova gate incorporates a palisade infill to match the surrounding perimeter fence, providing a continuous design that doesn’t look out of character. Inova specialist automatic gates UK.

Posted on

EDF Energy Bow Sub-Station for London Olympics 2012

This Inova Industrial Specialist sliding gate 380 ESI Model fully automatic gate, incorporates a prison mesh infill panel finish within the gate to match the perimeter fence.

The 5000mm x 4000mm high Inova high security sliding gate complete with prison mesh infill is a highly secure product ideal to keep intruder’s at bay. The prison mesh infill panels is excellent for applications were securely is priority as well as providing sufficient natural light into the compound. This high security gate comes complete with all safety edges, key activated switch, remote control, soft start and special inoflex control. High security Inova cantilevered sliding gates.

Posted on

National Grid Bicker Fenn Sub-Station

This 3300mm clear opening x 4000mm high Inova Industrial Specialist sliding gate 280 ESI Model fully automatic, was designed to provide a line of defence against outside intruders. Finished in grey (RAL 9006) to match the surrounding palisade perimeter fence (also by Inova Gates), this Inova sliding gate incorporates 10KV induced pulse wires with electro fence extensions which span from the ground level up to 1.6m above the sliding gate, and around the complete sub-station perimeter providing a highly secured area.

The Inova cantilevered sliding gate came with all safety edges, key activated switches and remote controls. The lower beam of this Inova gate is 600mm above ground level (Special Design).

Inova sliding Gates worked closely with our client the National Grid to provide the design of this high secure system.

Posted on

EDF Energy & Siemens for London Olympics 2012 Sliding Gate

This 6000 mm wide clear opening x 5000 mm high Inova industrial specialist sliding gate 400 ESI Model fully automatic, complete with integrated pedestrian gate is finished in a signal grey (RAL 7004) alloy sheeted surface and is designed to prevent terrorist attacks, intruder’s entering or seeing into the Olympic compound.

This automatic gate comes complete with all safety edges, key activated switches, remote controls, soft starts and inoflex special controls. The gates are made up of RHS vertical infill bars with alloy sheeting to give total vision block.

Inova automatic Gates worked closely with the main contractor’s “EDF Energy & Siemens” on this Olympic project in order to meet there design and site requirements, as well as providing a fast and efficient on-site installation without any hassle.
